Rated voltage
|
230V
|
Rated current
|
5(80) A
|
Constant
|
1000imp/kWh
|
Display
|
LCD 6+2
|
Relative humidity
|
≤85%
|
Rated frequency
|
50Hz
|
Accuracy degree
|
class 1
|
Power consumption
|
0.96W/2.524VA
|
Standard
|
|
Functional test
|
IEC62052-11:2003
|
Impulse output
|
IEC62053-21:2003
|
Protection degree
|
IP51
|
Communication protocol
|
DLMS
|
Material
|
|
Meter
|
base ABS
|
Meter
|
Cover ABS
|
Terminal
|
block LCP
|
Terminal
|
cover ABS
|
Panel
|
ABS
|
Tampering Protection Function
|
bypass power detection, record events and LED alarm.
|
open terminal cover detection, LCD alarm display and record the event.
|
record external magnetic field event.
|
record over voltage and low voltage event.
|
self-diagnostic: EEPROM check, battery alarm.
|
Display details
|
Total active energy power, voltage effective value, current effective value, average active energy on second, current date,
current time. |
Communication
|
RS485 communication, used for remote reading, remote controlling and local reading.
|
IR communication, used for local setting and reading.
|
M-BUS communication, used for reading and controlling the energy meter.
|
Events details
|
Over voltage, low voltage, bypass, current reverse, power off, open terminal cover.
|
Measurement
|
Single phase active energy measurement, keep records of power, average active energy on second, voltage effective value, current effective value, demand.
|
