Voltage:
|
3*230/400V
|
Current:
|
3*5(80)A
|
Accuracy class:
|
1
|
Standard:
|
IEC62052-11, IEC62053-21
|
Frequency:
|
50-60Hz
|
Impulse constant:
|
800imp/kWh
|
Display:
|
LCD 6+2
|
Power consumption:
|
≤2W, 10VA
|
Starting current:
|
0.004Ib
|
Working Temperature:
|
-20~55℃
|
Storage Temperature:
|
-25~70℃
|
Working voltage:
|
0.9—1.1 Rated voltage
|
Utmost voltage:
|
0.8—1.15 Rated voltage
|
Average humidity value of year:
|
≤75%
|
Creep:
|
Less than 1 impulse when the rated voltage is 115% or current loop without current.
|
Meter
|
Meter class
|
Power factor
|
||
1
|
2
|
3
|
||
Direct connect
|
0.004Ib
|
0.05Ib
|
0.01Ib
|
1
|
