LC1-D AC contactor

LC1-D AC Contactor Applications:

1) It is suitable for frequency 50/60Hz, rated voltage up to 660V, rated operation current 9~95A under AC-3 duty.

2) It is mainly used for making / breaking electric circuits at a long distance & for frequent starting / stopping & controlling AC Motors.

3) It can become the time-delay contactor, mechanical interlocking contactor, star-delta starter with other parts..

3) With the thermal relay, it is combined into the electromagnetic starter LC1-D AC Contactor

5) The products com-ply with IEC60947-4-1 standard.

LC1-D AC contactor: Main technical Parameter

Rated insulated voltage:660V

Type: LC1-D09 LC1-D12 LC1-D18 LC1-D25 LC1-D32

1. UnderAC-3, 380V---

--- rated operation current (A) 9 12 18 25 32

2. UnderAC-4, 380V---

--- rated operation current (A) 3.5 5 7.7 8.5 12

Conventional thermal current (A) 20 20 32 40 50

Under AC-3, controlled power (kW)

1.220V 2.2kW 3kW 4kW 5.5kW 7.5kW

2.380V 4kW 5.5kW 7.5kW 11kW 15kW

3.660V 5.5kW 7.5kW 10kW 15kW 18.5kW

Type: LC1-D40 LC1-D50 LC1-D65 LC1-D80 LC1-D95

1. UnderAC-3, 380V---

--- rated operation current (A) 40 50 65 80 95

2. UnderAC-4, 380V---

--- rated operation current (A) 18.5 24 28 37 44

Conventional thermal current (A) 60 80 80 110 110

Under AC-3, controlled power (kW)

1.220V 11kW 15kW 18.5kW 22kW 25kW

2.380V 18.5kW 22kW 30kW 37kW 45kW

3.660V 30kW 33kW 37kW 45kW 55kW

Max making current: 10 times of rated current (AC-3, 380V)

Max breaking current: 8times of rated current (AC-3, 380V) LC1-D AC Contactor

AC-4 electric life: CJX2-09~32(LC1-D09, LC1-D12, LC1-D25, LC1-D32) 200 000 times;

CJX2-405065 (LC1-D40, LC1-D50, LC1-D65) 150 000 times;

CJX2-8095 (LC1-D80, LC1-D95) 100 000 times

AC-3 electric life: CJX2-09~32(LC1-D09, LC1-D12, LC1-D25, LC1-D32) 1 000 000 times;

CJX2-405065 (LC1-D40, LC1-D50, LC1-D65) 800 000 times;

CJX2-8095 (LC1-D80, LC1-D95) 600 000times

Mechanical life: CJX2-09~32(LC1-D09, LC1-D12, LC1-D25, LC1-D32) 10 million times

CJX2-405065 (LC1-D40, LC1-D50, LC1-D65) 8 million times;

CJX2-8095 (LC1-D80, LC1-D95) 10million times

(TIANHUI EIECTRIC) LC1-D AC Contactor
