HSD-15KW Conveyor Belt Welding Machine for Cleats and sidewall

High Frequency Conveyor belt welding machine HSD-8KW /10KW/15KW/25KW

HANS WELDING MACHINERY ,Who are the specialist of High Frequency conveyor belt welding

machine in Chinese Market ,its machine are also sold to all around the world .

Our High Frequency Welder HSD-15KW is is designed and designed for T cleats ,Profile,

Guides and sidewall which is made of PVC or TPU (Thermoplastic).Meanwhile we offer our

customer one station service that customized heat resistant electrodes could be made.

Our H.F welder is equipped with the shielding case which flank side is removable for

the sidewall and to block the radiation emit from machine .side roll is fixed at flank

edges of the bottom working table which allows worker to pull the belt much easier

as well as ergonomic work space.



We offer our High Frequency Conveyor belt machine which H.F power output from 8KW to

25KW for various of PVC &TPU Cleats,profile,sidewall and guides.

HSD-15KW

Conveyor Belts ,T-Cleats and Fabricated Cleats ,Sidewalls

Model HSD-15KW

Power 15000W

Power Supply 380V 3P 50HZ

Frequency 27.12MHz

Input power 25KVA

Rectifier SILICON DIODE

Oscillation tube 8T85RB

Max pressure 1500KG

Gap of electrodes 250MM

Cylinder Stroke 150MM

Size of upper electrode 400*800MM

Size of bottom electrode 400*800MM
