Four -Head Windows Welding Machine

2013 Brand New Four -Head Windows welding machine



Main Features:



This machine is the production of plastic doors and Windows of main equipment, which can realize four, three, two, one point, Ting, the cross in Ting, different Angle welding, four head can work together at the same time, also can respectively the combination or single work alone. No oil lubrication bearing the CM motion pair, high accuracy, especially the control part USES the import original PLC machine so the reliability is greatly increased.



Technical specifications:



Equipment model SHZ4-120 X 4500

Input voltage of 380 V / 220 V frequency 50 Hz

The input power 4.5 Kw

Working pressure 0.4 ~ 0.6 MPa

Gas consumption 200 L/min

Welding profiles 400 ~ 4500 mm length

Welding profiles 20 to 120 mm height

Shape dimension 5300 X 950 X 1700 mm



Guarantee & Aftersales service:

1. Guarantee for one year

2.24 hour technical support by email or calling

3. User-friendly English manual for machine using and maintaining
