Potato Tomato Freeze Bean Sprout Drying Conveyor Machine/Bean Sprout Dryer

Structure: Chain Conveyor

Material: Stainless Steel

Material Feature: Oil Resistant, Anti-Corrosion

Application: Chemical Industry, Grain Transport, Power Plant, Food Industry

Condition: New

Design Standard: Food Standard Conveyor

Life Time: 5-8 Years

Size: All Can Customized

Usage: Heating, Cooling All Can Use

High temperature Resistance: 200 Degree

Trademark: RF or Customized

Description:

Multilayer belt dryer is specially designed for drying different shapes of root vegetables and leafy vegetables. This drying machine has three-layer and five-layer structure, each layer can be independently adjusted the drying temperature according to the characteristics of the materials.

The working principle of this multilayer conveyor dryer shows as follows: the material is limit controlled by the hopper and is evenly spread on the mesh belt. The materials are driven by the motor to the top layer, then perform uniform motion in the multilayer belt dryer and conduct downward movement layer by layer. Cold air enters from the two axial flow fans, after ballasting via baffle plate, it will flows from bottom to top. There is equipped with a heater under the mesh belt at each layer. The cold air is constantly gradient heated, and then through the material layer. It will conduct mass transfer and heat transfer with the material layer, so that the moisture contained in the material can be rapidly vaporized and evaporated. When the cold air gets to the top layer, it has become saturated moist air, and will be discharged outdoors under the action of exhaust fan.

Applications:

• Multilayer belt dryers are extensively used for dehydrating and drying the sheet type, stripe type and granular materials in the industries of food, agricultural products, dehydrated vegetables, Chinese medicinal materials, seafood, native products, feed and chemical materials.

Features:

• The hot gas flow passes through the mesh belt and the material layer from bottom to top, thus ensuring uniform heat transfer. This drying machine has high production efficiency and good quality.
• This multilayer conveyor dryer adopts hoisting equipment with uniform feeder, and the thickness of the material layer can be infinitely variable control.

Our advantages:

1. High strength food grade SUS304 stainless steel spiral belt, with side guards at both sides, prevent the products from falling down.
2. Tension device of spiral belt adopts floating shaft, which can automatically adjust the tightness of the mesh belt and ensure the smooth and reliable operation of the mesh belt when the temperature changes or the force changes.
3. All stainless-steel frame, sanitary hygiene, reasonable structure, easy to clean. Non-toxic, tasteless, wear-resistant polymer polyethylene (molecular of more than 4 million) material, which can ensure the whole machine long service life and healthy safety.

Please note below Parameters when you ask for a quotation:

1. Overall Length and C/C center

2. Rod Pitch and Spiral Pitch

3. Wire Diameter, Chain Pitch

4. Support Rod Pitch and Support Rod Diameter

If you don't know the data above, please contact us, we will give you the best advice.
